Features:
- Classic Design
- Aluminium Alloy Body and Pistons
- High Temperature Seals
- Machined from high quality casting
- Hard anodised surface treatment
Typical Applications
- F2 Side Car
- Classic Racing
- Road Motorcycles
| Pad Family |
CP2195D38 |
| Piston Diameter mm |
41.3 x 2 |
| Total Piston Area cm² |
26.8 |
| Disc Diameter Max mm |
304 |
| Disc Thickness mm |
6.4 |
| Weight Kg |
0.9 |
| Hydraulic Threads |
3/8 x 24UNF |
| Mounting Centres - mm |
89 |
| Offset - mm |
19.1 |
| Mounting Hole Diameter - mm |
10.2 |
| Bleed Screw Tightening Torque |
17Nm (12.5lbs/ft) |
| Spare Parts |
Part Numbers |
| Seal Repair Kit |
CP4518-K |
| Pistons |
CP2055 x 1 / CP2195-9 x 1 |
| Pad Retainer |
Split Pin - CP2696-160 x 2 |
| Bleed Screw |
CP3720-182 |
